Grower Plus Series High Tunnels, with a double-layer roof and polycarbonate end walls.
The same commercial-grade frame as every CT Greenhouse high tunnel, with the upgrades growers ask for most already standard: 8mm twin-wall polycarbonate end walls, an inflated double layer of 6-mil poly, automatic peak vents, and 8' x 7' double hinged doors.
The Grower Plus is a starting point, not a box: width, length, height, end walls, and hardware all configure to your operation.
Every Grower Plus starts from your farm.
Each kit is configured on your quote: width, length, sidewall height, end walls, doors, and hardware.
Dimensions
Any width from 14 to 34 ft in 2-ft steps, any length in multiples of 4 ft, and standard (5 ft) or tall (6 ft) sidewalls.
End walls & doors
Steel-framed end walls: poly film on the Grower, twin-wall polycarbonate on the Plus and Pro. Doors are 8' x 7' double doors (two 4' doors), hinged or sliding.
Ventilation & sides
Roll-up sides with a 5:1 locking gear crank (7:1 or 13:1 heavy-duty cranks for longer tunnels). Options include a ridge vent package and roll-up automation (motor and controller), and powered peak vent openers are available.
Specifications by model
Your model is highlighted. All four models are configured to your site.
| Specification | Grower | Grower Plus | Grower Pro | Powerhouse |
|---|---|---|---|---|
| Main bow tubing | 1.9" 13-ga galvanized | 1.9" 13-ga galvanized | 1.9" 13-ga galvanized | Configured with you |
| Purlins | 1.315" 16-ga | 1.315" 16-ga | 1.315" 16-ga | Configured with you |
| Hardware | Grade 5 bolts, wirelock hip boards | Grade 5 bolts, wirelock hip boards | Grade 5 bolts, wirelock hip boards | Configured with you |
| Width range | 14–34 ft | 14–34 ft | 14–34 ft | Configured with you |
| Top covering | Single-layer 6-mil | Double-inflated 6-mil | Double-inflated 6-mil | Double-inflated 6-mil |
| End walls | Steel-framed, 6-mil poly | Steel-framed, 8mm twin-wall polycarbonate | Steel-framed, 8mm twin-wall polycarbonate | Configured with you |
| Doors | Add-on | 8'×7' double hinged | 8'×7' double sliding | Configured with you |
| Roll-up sides | Manual, 5:1 gear crank | Manual, 5:1 crank, bug netting | Manual, 5:1 crank, Solarside woven sides, bug netting | Configured with you |
| Peak vents | Add-on | Automatic, no power needed | Automatic, no power needed | Configured with you |
| Baseboards | Hardware for local lumber | Hardware for local lumber | Steel + polycarbonate system | Configured with you |
| Trellis | Add-on | Add-on | Cable support system included | Configured with you |
What's in the kit
- Frame: 1.9" 13-gauge galvanized main bows with a 16-gauge truss on every bow, 1.315" 16-gauge purlins and ridge, steel-framed end walls, and ground posts.
- Hardware: Grade 5 bolts at every major connection, stainless steel wiggle wire and self-tapping screws, and aluminum double wirelock hip boards.
- Covering: an inflated double layer of 6-mil greenhouse plastic with the inflation blower, and steel-framed 8mm twin-wall polycarbonate end walls.
- Venting: end wall peak vents with automatic wax-cylinder openers, roll-up sides with 5:1 locking gear cranks, bug netting under the sides, and corner wind braces.
- Doors: 8' x 7' double hinged doors (two 4' doors) on each end.
- Baseboard hardware: everything needed to attach locally sourced lumber (we recommend 2x10s). Plan a standard 120V outlet near the tunnel for the blower.
- Build guidance: written assembly instructions, and an owner available by phone.
Planning to apply for EQIP cost-share?
This structure is designed to meet NRCS Conservation Practice Standard 325, and we supply the documentation your application needs. Eligibility and cost-share rates vary by state, and we'll point you to yours.
Asked about the Grower Plus.
The Grower Plus has all the same main specs as the Grower, with the addition of: an inflated double layer of 6-mil poly with the blower, 8mm twin-wall polycarbonate end walls, automatic peak vents, 8′×7′ double hinged doors, and bug netting.
The full galvanized steel frame, steel-framed 8mm twin-wall polycarbonate end walls, an inflated double layer of 6-mil greenhouse plastic with the blower, automatic end wall peak vents, 8' x 7' double hinged doors on each end, roll-up sides with 5:1 gear cranks, bug netting under the sides, and corner wind braces. You source baseboard lumber locally, and the blower needs a standard 120V outlet near the tunnel.
Yes. NRCS funds the practice rather than approving vendors, and the Plus is designed to meet Conservation Practice Standard 325. We provide the documentation your local NRCS office needs; size limits and cost-share rates vary by state.
NRCS reimbursement generally runs $4 to $8 per square foot of high tunnel, though the exact rate, payment caps, and eligibility all vary by state and program year. Your local NRCS office can give you the current figures for your area.
We started out as growers ourselves in the Northeast, so our tunnels have been intended from the start to handle harsh winters. The gothic design is a must for shedding snow effectively, and we always spec a 16-gauge truss on every bow.
Width, length, and sidewall height are configurable: any width from 14 to 34 feet, any length in multiples of 4 feet, and standard or tall sidewalls.
Let's configure your Grower Plus.
Tell us about your operation and an owner will follow up with a quote for your site. Ask us about EQIP cost-share; rates vary by state.
